    Size 160ml/R Hydraulic Motor Spool Valve M02096AC01AA Eaton Replace BMK2-160-E2KSU

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : BMK2-160-E2KSU
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, Payple
    Supply Ability : 10000 pieces per year
    Delivery Time : 10 - 15 work days
    • Product Details
    • Company Profile

    Size 160ml/R Hydraulic Motor Spool Valve M02096AC01AA Eaton Replace BMK2-160-E2KSU

    Hydraulic Drive Motor M02096AC01AA Eaton replace BMK2-160-E2KSU



    This motor is one special type motor to replace Eaton 2000 (2K) series.
    This motor is one special type motor to replace OMS series.

    Model number: BMK2-160-E2KSU

    Specifications:

    • motor BMK2
    • displacement 160 = 160ml/r
    • flange E2 = 2-13.5 rhomb-flange, pilot 82.5x6.4mm
    • output shaft K = shaft 25.4mm, woodruff key 25.4x6.35
    • port and drain port SU = 7/8-14 UNF O-RING, 7/16-20UNF
    • rotation = standard
    • paint = BLUE

    Market we serve:


    • Turf Equipment
    • Aerial
    • Agriculture Machinery
    • Construction Equipment
    • Factory Automation
    • Material Handling Equipment
    • Oil & Gas
    • Forestry Equipment
    • Mining

    Features/Benefits:


    • Robust construction for longer life
    • Continuous oil flow across internal splines for longer life
    • Superior side load capacity
    • Smooth, extra low speed operation
    • High pressure shaft seal is standard
    • Innovative design eliminates the need for a drain
    • Dependability based on high quality design and manufacturing
    • Designed and manufactured in Greeneville, TN USA

    Applications:


    • Trenchers
    • Skid Steer Attachments
    • Zero Turn Mowers
    • Golf Course Maintenance Equipment
    • Sweepers
    • Wood Chippers
    • Conveyers
    • Combine Harvesters
    • Winches
    • Augers
    • Portable Irrigation Systems
    • Post Hole Augers
    • Potato, Tomato, Nut, Leafy Vegetable, Sugar, Cotton, Coffee and Grape Specialty Harvesters
    • Combine Header Drives
    • Sprayers
    • Scissor Lifts
    • Snow Removal
    • Salt and Sand Spreaders
    • Oil and Gas Blender Trucks
    • Mini and Walk-Behind Skid Steers
    • Tool Carriers
    • Pipe Spinners


    Main Specifications:
    TypeBMK2BMK2BMK2BMK2BMK2BMK2BMK2BMK2BMK2BMK2
    6580100125160200250315400475
    Geometric displacement
    (cm3 /rev.)
    6580100.9129.8156.8193.4242.5304.3390.8485
    Max. speed (rpm)cont.835800742576477385308246191153
    int.990980924720713577462365287230
    Max. torque (N·m)cont.185235295385455540660765775845
    int.245345445560570665820885925930
    Max. pressure drop (MPa)cont.20.521212120.520.520.52115.512
    int.27.5313131262626241714
    peak313131313131313120.517
    Max. flow (L/min)cont.55657575757575757575
    int.65809595115115115115115115
    Weight (kg)9.29.49.71010.210.51111.51212.4
    * Continuous pressure :Max. value of operating motor continuously.
    * Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.



    Please do not hesitate to contact us for further information, inquiries or orders.

    Thank you for choosing 'Hanjiu' Hydraulics.
