    OMS MS BMK2 Hydraulic Motor 250ml/R With Shaft Gear And Balance Valve

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : 2.5K-250-A-A-A
    Certification : CE, ISO9001
    Price : 120 usd/pc
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 10000 pieces per year
    Delivery Time : 0 - 35 work days
    • Product Details
    • Company Profile

    OMS MS BMK2 Hydraulic Motor 250ml/R With Shaft Gear And Balance Valve


    Quick review:

    Model Number:

    2.5K-250-A-A-A


    Details:

    ProductGerotor Hydraulic Motors
    Model No.2.5K-250-A-A-A
    Size250 ml/r
    Pilot110mm
    Shaft11T
    RotationLeft and Right
    PortG 1/2
    FeaturesDanfoss Eaton Charlynn 2000 series interchangeable

    Specification:

    Main Specifications:
    TypeBMK2BMK2BMK2BMK2BMK2BMK2BMK2BMK2BMK2BMK2
    6580100125160200250315400475
    Geometric displacement
    (cm3 /rev.)
    6580100.9129.8156.8193.4242.5304.3390.8485
    Max. speed (rpm)cont.835800742576477385308246191153
    int.990980924720713577462365287230
    Max. torque (N·m)cont.185235295385455540660765775845
    int.245345445560570665820885925930
    Max. pressure drop (MPa)cont.20.521212120.520.520.52115.512
    int.27.5313131262626241714
    peak313131313131313120.517
    Max. flow (L/min)cont.55657575757575757575
    int.65809595115115115115115115
    Weight (kg)9.29.49.71010.210.51111.51212.4
    * Continuous pressure :Max. value of operating motor continuously.
    * Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.





    The BMK2 series motor adapts the GEROLER gear set design with high speed distribution flow and high pressure. These motors can be supplied with various options for multifunctional operations in accordance with the application requirements. These low weight advanced construction design motors are manufactured in accordance with the requirements of ISO 9001-2000 quality system.


    More BMK2 series to match Danfoss Eaton Charlynndrive motors


    EATON CHAY-LYNN Hydraulic Motors
    • J (129-)
    • H (101-)
    • S (103-)
    • T (158-)
    • W (162-)
    • 2000 (104-, 105-, 106-, 193-)
    • 4000 (109-, 110-, 111-)
    • 6000 (112-, 113-, 114-)
    • 10000 ( 119-)


    Hanjiu Technology Company production of LSHT hydraulic motors, a wide variety of types, their production of motors for the main markets of hydraulics including construction, agriculture, traditional industry, metallurgy, mining, shipbuilding and horticulture and other fields, Hanjiu company relies on its strong global distribution network to sell their products to various countries and regions, in many places can appreciate the Hanjiu technology hydraulic motors to provide fast and convenient services.
