    Float Function 2 Spool 40 Liters Monoblock Valves 3/8" Spring Return

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : 2P40
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, Western Union, T/T
    Supply Ability : 1000000 sets per year
    Delivery Time : 25 - 35 work days
    • Product Details
    • Company Profile

    Float Function 2 Spool 40 Liters Monoblock Valves 3/8" Spring Return

    Float Function 2 Spool 40 liters monoblock valves 3/8'' spring return


    We are professional manufacturer to produce Hydraulic Monoblock and Sectional Directional Control Valves to suit hydraulic systems of agricultural, forestry, construction, minging, transport, industrial, drilling machine, sanitation and many more


    We have many options for the monoblock and sectional types

    It's available from 40 liters - 200 liters, and upto 1 spools are also provided by us

    Also manual, joystick, cable, pneumatic, solenoid, electro-pneumatic, electro-hydraulic control types

    Ambient temperature-40C...+60C
    Viscosity12 ...800 mm2/s
    Fluid temperature-15C...+80C
    Filtration10 to NAS 1638
    Max operating pressure315 bar
    Back pressure50 bar
    Nominal flow40 l/min
    Leakage(A,B-T)15cm3/min at 120bar
    Spool stroke+/-7 mm
    Actuating force< 200 N
    Modification/ Spools1 to 8
    Monoblock valveFlowNom. PressureSpool
    P4040L/Min

    E 16 MPa

    F 20 MPa

    1
    P4040L/Min

    E 16 MPa

    F 20 MPa

    2
    P4040L/Min

    E 16 MPa

    F 20 MPa

    3
    P4040L/Min

    E 16 MPa

    F 20 MPa

    4
    P4040L/Min

    E 16 MPa

    F 20 MPa

    5
    P4040L/Min6
    P8080L/Min

    E 16 MPa

    F 20 MPa

    1
    P8080L/Min

    E 16 MPa

    F 20 MPa

    2
    P8080L/Min

    E 16 MPa

    F 20 MPa

    3
    P8080L/Min

    E 16 MPa

    F 20 MPa

    4
    P8080L/Min

    E 16 MPa

    F 20 MPa

    5
    P8080L/Min

    E 16 MPa

    F 20 MPa

    6
    P120120L/Min

    E 16 MPa

    F 20 MPa

    1
    P120120L/Min

    E 16 MPa

    F 20 MPa

    2
    P120120L/Min

    E 16 MPa

    F 20 MPa

    3
    P120120L/Min

    E 16 MPa

    F 20 MPa

    4
    P120120L/Min

    E 16 MPa

    F 20 MPa

    5
    P120120L/Min

    E 16 MPa

    F 20 MPa

    6
