    Automation Components & Systems Hydraulic Valves 20 Liters To 200 Liters

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : DCV
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, Western Union, T/T
    Supply Ability : 1000000 sets per year
    Delivery Time : 19 work days
    • Product Details
    • Company Profile

    Automation Components & Systems Hydraulic Valves 20 Liters To 200 Liters


    Automation components & systems Hydraulic Valves 20 liters to 200 liters


    We manufacture and export automation power components and actuators
    We manufacture and export a wide range of hydraulic control valves, including monoblock and split


    Available manual, pneumatic control, electric and pneumatic control ,hydraulic and electric control.
    PARAMETERS

    Nom. Pressure
    (MPa)
    Max.Pressure
    (MPa)

    Nom. Flow rate (L/min)

    Back Pressure(MPa)
    hydraulic oil
    Tem.rang
    (ºC)
    Visc.rang
    (mm2/S)
    filtrating accuracy
    (μm)
    3531.5200≤1-40~+8010~400≤10

    DCV valveFlowNom. PressureSpool
    DCV 2020L/Min100 ~315 BAR1-12 sections
    DCV 4040L/Min100 ~315 BAR1-12 sections
    DCV 4545L/Min100 ~315 BAR1-12 sections
    DCV 6060L/Min100 ~315 BAR1-12 sections
    DCV 100100L/Min100 ~315 BAR1-12 sections
    DCV 140140L/Min100 ~315 BAR1-12 sections
    DCV 200200L/Min100 ~315 BAR1-12 sections

    DCV directional control valve have the features of below
    1, high pressure,
    2, compact construct,
    3, stable over load valve
    4, performance and high universality.
    5, Auxiliary valve:over load valve, anti-cavitation valve, combined valves, etc.
    6, Spool function:A, O, Y, P, etc.
    7, Control type:manual, joystick, cable, pneumatic, electro-hydraulic, electro-pneumatic, etc.
    8, Circuit type:parallel,series-parallel
    9, Carry-over port as hydraulic source for other parts
    10, Structure:Monoblock, sectional

    Application:
    This product is applicable to special vehicles like truck mounted crane, wrecker, scrubbing machine and dynamic compactor and can effectively control such actuating mechanisms like motor and oil cylinder.


    How to choose the model you need?


    DCV XX / X - X X X - X X X X - X X X X ... -X - X X
    (1) Flow: 40, 45, 60, 100, 140, 200
    (2) Number of spools: 1-12
    (3) Inlet section type: see table (1)
    (4) Relief valve set pressure: 150-315 bar
    (5) Inlet port size: see table (2)
    (6) Spool type: see table (3)
    (7) Spool handle side arrangement: see table (4)
    (8) Spool cap side arrangement: see table (5)
    (9) Working section arrangement: see table (6)
    (10) Work port size: see table (2)
    (11) Outlet section type: see table (7)
    (12) Outlet port size: see table (2)

    You can also find the structure of the valves at the bottum of this artical





    More related hydraulic items for hydraullic systems



    Hanjiu customizes and designs products for different kinds of companies: Hydraulic Resellers, Hydraulic Distributors, Hydraulic Machines Manufacturers, Hydraulic Training, Hydraulic Fluid Tech Research, Hydraulic Repairing, Fluid Power Manufacturers, Hydraulic Systems Solutions, Fluid Power Solutions etc.
