    Fluid Power Systems Orbit Hydraulic Motor Brake B/Mr Integral Brake Motor Compact Hydraulic Components

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : BMR-bk01
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, Payple
    Supply Ability : 300000 pieces per year
    Delivery Time : 25-30 work days
    • Product Details
    • Company Profile

    Fluid Power Systems Orbit Hydraulic Motor Brake B/Mr Integral Brake Motor Compact Hydraulic Components


    Fluid power systems Orbit Hydraulic Motor-brake B/MR integral brake motor compact hydraulic components


    Specifications:

    1. B/MR = M+S B/MR
    2. displacement = 160cc
    3. 2= 2-Ø13.5Rhomb-flange, pilot Ø82.5×8
    4. A = Shaft Ø25mm
    5. D = G1/2 Manifold Mount, 4-M8, G1/4

    Shijiazhuang hanjiu technology is strong at motor produce, type , Eaton, Char-lynn, Parker, White, Brevini, TRW, M+S can be provided,good quality,affordable price, fast delivery time and best after sales service.


    Suitable in many hydraulic motor markets, the hydraulic motor with integral brake is ideal for applications where space in the overall machine design is an issue.

    This solution eliminates the need for a separate braking unit and provides up to 1580 Nm [14,000 lb-in] of reliable holding torque in a single compact package.

    Features and benefits
    The compact housing design provides a high power to weight ratio

    The heavy duty drive link is the most durable in its class, receiving full flow lubrication for reduced wear and overall increased motor life

    The three zone orbital valve precisely meters oil to produce exceptional volumetric efficiencies

    A rubber energized, steel faced seal in the orbital valving provides greater protection against seal extrusion and overheating

    A standard drain increases the overall shaft seal life by reducing the pressure on the shaft seal



    Specifications:



    Applications:

    1.conveyors

    2.Feeding mechanism of robots and manipulators
    3.Metal working machines
    4.Textile machines
    5.Agriculture machines
    6.Food industries
    7.Mining machinery



    Hanjiu hydraulic is the perfect hydraulic manufacture for your hydraulic components,Hydraulic solutions supplier
