    Steering Unit With Priority Valve 100CC Crossover HKUS/5-125+PRD80/4

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : 101s-5t-HC
    Certification : CE
    Price : Contact the seller to ask
    Payment Terms : L/C, T/T, D/P, Western Union
    Supply Ability : 1000000 Sets Per Year
    Delivery Time : 25 - 35 work days
    • Product Details
    • Company Profile

    Steering Unit With Priority Valve 100CC Crossover HKUS/5-125+PRD80/4

    Steering Unit with Priority Valve 100CC, Crossover HKUS/5-125+PRD80/4


    STEERING UNIT+PRIORITY VALVE


    Part number: 101S-5T+PVSD80

    Crossover: HKUS/5-125+PRD80/4

    Weight: 9 kg

    Purchase at least: 1 pc

    Manufacturer: HANJIU HYDRAULIC


    LS valve = 125 bar

    Anti-shock valve = 175 bar


    Specifications:


    ParametersSeries: 101s similar to OSPC
    Function code1,2,41,4
    Displacement (mL/r)506380100125160200250280315400
    Rated Flow (L/min)5681012.5162025283240
    Max.input pressure (Mpa)16
    Relief Valve Pressure ( MPa)06,07,08,10,12,14,15,16
    Shock Valve Pressure ( MPa)12,13,14,16,18,20,21,22
    Max.cont.back pressure2.5
    Weight(kg)5.755.815.895.966.16.36.56.736.917.17.5
    Dimension L (mm)130132134137140145150156161166176

    We provide orbitrol for Agri and heavy tractors, loaders, forklifts, boats, and many more.

    Form, fit, and function the same M+S, Eaton, Danfoss, Catterpillar, Komatsu, Volvo, Youli, Bobcat, John Deere, and many more, at a substantial savings





    Please send your request list to ask a best quote

    Probably you also interest other hydraulics, contact us, send your request list, we will check and reply with best offer aswell
