    151F5102 OMS 125 Cylindrical 32mm Shaft danfoss hydro motor With BSP Port G1/2

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : BMS
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000000 sets per year
    Delivery Time : 10-15 work days
    • Product Details
    • Company Profile

    151F5102 OMS 125 Cylindrical 32mm Shaft danfoss hydro motor With BSP Port G1/2

    DANFOSS 151F5102 Similar Motor, OMS 125 Cylindrical 32mm Shaft with BSP port G1/2


    This motor is a high-quality alternative to Danfoss OMS eries, with a very high price performance
    The full model is 151F5102
    Here are the parameters


    Basic Motor: BMS
    Size: 125
    Mounting Flange: Standard
    Shaft Style: cylindrical
    Shaft Size: 32 mm
    Port Style: side port
    Port Size: G 1/2
    Drain Port: Standard
    Painting: Black
    Shaft Seal: Standard

    Specifications:


    TypeBMS
    BMSE
    80
    BMS
    BMSE
    100
    BMS
    BMSE
    125
    BMS
    BMSE
    160
    BMS
    BMSE
    200
    BMS
    BMSE
    250
    BMS
    BMSE
    315
    BMS
    BMSE
    375
    Geometric displacement
    (cm3 /rev.)
    80.6100.8125157.2200252314.5370
    Max. speed (rpm)cont.800748600470375300240200
    int.988900720560450360280240
    Max. torque (N·m)cont.190240310316400450560536
    int.240300370430466540658645
    peak260320400472650690740751
    Max. output (kW)cont.15.918.819.515.615.714.114.111.8
    int.20.123.523.221.218.31718.917
    Max. pressure drop (MPa)cont.17.517.517.5151412.51210
    int.2121212116161412
    peak22.522.522.522.522.52018.514
    Max. flow (L/min)cont.6575757575757575
    int.8090909090909090
    Max. inlet pressure (MPa)cont.2525252525252525
    int.3030303030303030
    Weight (kg)9.81010.310.711.111.612.312.6

    * Continuous pressure :Max. value of operating motor continuously.
    * Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.


    BMSY new series motor adapt the advanced Geroler gear set designed with disc distribution flow
    and high pressure.The unit can be supplied the individual variant in operating multifunction in
    accordance with requirement of applications.
    Characteristic featutres:
    * Advanced manufacturing devices for the Geroler gear set, which use low pressure of start-up, provide smooth and
    reliable operation and high efficiency.
    * The output shaft adapts in tapered roller bearings that permit high axial and radial forces. The can offers
    capacities of high pressure and high torque in the wide of applications.
    * Advanced design in disc distribution flow, which can automatically compensate in operating with high volume
    efficiency and long life , provide smooth and reliable operation.
    * The new series motor is suitable for vehicles with greater loads and pressure drop
