    BMSY Hose Reels Hydraulic Drive Motor Hose Handling Systems High Performance

    Ask Lasest Price
    Brand Name : HANJIU CHINA
    Model Number : BMSY 500
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, Payple
    Supply Ability : 100000 pieces per year
    Delivery Time : 25 - 35 work days
    • Product Details
    • Company Profile

    BMSY Hose Reels Hydraulic Drive Motor Hose Handling Systems High Performance


    BMSY series hose reels hydraulic drive motor Hose Handling Systems high performance


    BMSY new series motor adapt the advanced Geroler gear set designed with disc distribution flow
    and high pressure.The unit can be supplied the individual variant in operating multifunction in
    accordance with requirement of applications.
    Characteristic featutres:
    * Advanced manufacturing devices for the Geroler gear set, which use low pressure of start-up, provide smooth and
    reliable operation and high efficiency.
    * The output shaft adapts in tapered roller bearings that permit high axial and radial forces. The can offers
    capacities of high pressure and high torque in the wide of applications.
    * Advanced design in disc distribution flow, which can automatically compensate in operating with high volume
    efficiency and long life , provide smooth and reliable operation.
    * The new series motor is suitable for vehicles with greater loads and pressure drop

    Main Specifications:

    TypeBMSY
    80
    BMSY
    100
    BMSY
    125
    BMSY
    160
    BMSY
    200
    BMSY
    250
    BMSY
    315
    BMSY
    400

    BMSY

    475

    Geometric displacement
    (cm3 /rev.)
    80.6100.8125157.2200252314.5394475
    Max. speed (rpm)cont.800748600470375300240

    185

    155
    int.988900720560450360280225185
    Max. torque (N·m)cont.190240310316400450560880910
    int.240300370430466540658980990
    peak260320400472650690740751
    Max. output (kW)cont.15.918.819.515.615.714.114.1119
    int.20.123.523.221.218.31718.91211
    Max. pressure drop (MPa)cont.17.517.517.5151412.5121614
    int.212121211616141915
    peak22.522.522.522.522.52018.52117.5
    Max. flow (L/min)cont.657575757575757575
    int.809090909090909090
    Max. inlet pressure (MPa)cont.252525252525252525
    int.303030303030303030
    Weight (kg)9.81010.310.711.111.612.312.614.3

    * Continuous pressure :Max. value of operating motor continuously.
    * Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.


    Product details


    Flange:4 bolts square flange φ106.4,pilotφ82.5X6.3

    shaft:Shaft Ø 32 , parllel key 10×8×45

    ports:G1/2 Manifold Mount;4/1G , 01M-2



    different types with different shafts,multipal flange
