    Hydraulic Motor MV400K OMV400 BMV400 Square Mount 4 Bolts Ø60 Tapered 1/10 With G1 Manifold Ports

    Ask Lasest Price
    Brand Name : HANJIU CHINA
    Model Number : BMV-400-4-T-d
    Certification : CE
    Price : Contact the selle to get the best offer
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 100000 sets per year
    Delivery Time : 0 - 35 work days
    • Product Details
    • Company Profile

    Hydraulic Motor MV400K OMV400 BMV400 Square Mount 4 Bolts Ø60 Tapered 1/10 With G1 Manifold Ports


    Hydraulic Motor MV400K,OMV400,BMV400,square mount 4 bolts, ø60 tapered 1:10 with G1 manifold ports


    This series is the BMV series hydraulic motor
    Model: BMV-400-4-T-D
    Displacement: 400 ml/r
    Flange: 4-Ø18 Square-flange Ø160, pilot Ø160X11
    Shaft: Cone shaft Ø60, parallel key 16×10×32
    Rotation :Standard


    Main Specifications:

    TypeBMV 315BMV 400BMV 500BMV 630BMV 800BMV 1000
    Geometric displacement (cm3 /rev.)333419518666801990
    Max. speed (rpm)cont.510500400320250200
    int.630600480380300240
    Max. torque (N·m)cont.92011801460166018802015
    int.111014101760194021102280
    peak129016402050221024702400
    Max. output (kW)cont.384747403328.6
    int.465656564440
    Max. pressure drop (MPa)cont.202020181614
    int.242424211816
    peak282828242118
    Max. flow (L/min)cont.160200200200200200
    int.200240240240240240
    Weight (kg)31.832.633.534.936.538.6

    * Continuous pressure :Max. value of operating motor continuously.
    * Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.






    Application:

    Key Applications

    Construction Equipment

    Excavators Driving tracks, swing mechanisms, and attachments.

    Cranes Rotating and lifting operations.

    Drilling rigs Powering drilling mechanisms and auxiliary functions.

    Agricultural Machinery

    Tractors Driving tracks or wheels, powering implements.

    Harvesters Operating various components like feed systems and conveyors.

    Industrial Machinery

    Conveyors Providing power for belt or roller conveyors.

    Mixers Driving mixing blades in various industrial processes.

    Presses Applying force for various industrial applications.

    Marine Applications

    Winches Powering lifting and lowering operations.

    Steering systems Providing power for steering mechanisms.

    Thrusters Generating propulsion for marine vessels.

    Mobile Equipment

    Forklifts Driving wheels and lifting masts.

    Aerial work platforms Powering platform rotation and extension.

    Specific Applications Based on Motor Characteristics

    High torque, low-speed applications Excavator tracks, heavy-duty mixers.

    Medium torque, medium-speed applications Conveyors, agricultural machinery components.

    High-speed applications Some specialized orbital motors can be used in applications requiring higher speeds, such as certain pump drives.

    Would you like to explore a specific application in more detail or discuss the selection of an orbital motor for a particular project.pls talk to me!
