    P40 Series Power Beyond Option P40 Electric And Hydraulic Control Valve For Sanitation Vehicles

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : P40-3-DC
    Certification : CE
    Price : Contact the seller to get a quote
    Payment Terms : L/C, T/T, Western Union, Western Union
    Supply Ability : 300000 sets per year
    Delivery Time : 25 - 35 work days
    • Product Details
    • Company Profile

    P40 Series Power Beyond Option P40 Electric And Hydraulic Control Valve For Sanitation Vehicles


    P40 Series Power Beyond Option P40 Electric and Hydraulic Control Valve for Sanitation Vehicles


    Solenoid direct control with spring return to neutral position.
    Needs special spools and special body P40DC=Z50


    3P40DC=03Z50-A-ES3-12VDC-G



    Control type:
    electro-hydraulic,solenoid


    Circuit type: parallel


    Application :


    Cranes, Telescopic boom fork lifts, Back-hoe Excavators and Compactors,Sanitation Vehicles


    flow rate40 liters
    number of spools3 spools
    inlet section valveside inlet, with relief valve
    relief valve set pressure200bar
    inlet port sizeG1/2
    spool type3 positon, double acting
    handle side arrangementstandard type
    spool cap side arrangement3position, spring return,manual control,detent control,
    working section arrangementstandard type
    work port sizeG3/8
    outlet section typetop outlet,side
    outlet port sizeG1/2


    Different types



    HANJIU Technology specialized in producing directional flow control valve, directional control hydraulic valve, multiple control spool valve, high pressure multi-port valve and etc. Our products are with outstanding performance, convenient operation, and our products are widely applied to agriculture, construction, petroleum, fishery, mining and other industries. In additional, we can also offer high quality hydraulic gear pumps.


    We have ISO9001:2015 quality management system. And due to the superior quality and considerate service we offer, we have became the leader in the industry. And we always keep dedicating on designing , researching, producing new products according to the market and our customers’ requests. Our products have already exported to Southeast Asia, Australia, the Middle East, Africa and Latin America and etc.


    Customer satisfaction is our ultimate goal at HANJIU. We will continue to further optimize our business management system and after-sales service system, so we can provide customers around the work with the best possible spool valves and gear pumps, backed by our excellent service. We always do our best to meet all the need of our customers.
